When rain blows in off the water and a puddle shows up inside the garage, the rubber strip along the bottom of the door is the first suspect. Often it is the right one. But in a wet Lower Mainland autumn a new bottom seal can do nothing at all if the water is coming in at the sides, between the sections, or under a slab that slopes the wrong way. This guide shows you how to tell which problem you have, how to match and fit the right seal, and what to check afterwards so the opener still stops safely.
First, find where the water is actually getting in
The Door & Access Systems Manufacturers Association (DASMA) is blunt about this in its Technical Data Sheet No. 1503: sectional garage doors "are not leak proof or watertight." It lists three ways rain gets past a closed or opening door. Each one points to a different fix.
Water across the whole width of the door
A wet band along the entire bottom edge usually means the bottom seal is flattened, torn, shrunk short of the ends, or not touching a floor that dips in the middle. This is where a garage door bottom seal replacement helps most.
Water at the corners and down the sides
DASMA notes that rain can collect in the joints between sections, run sideways to the ends of the door and get past the perimeter seal. Wind-driven rain can also push straight through at the sides. A new bottom seal will not stop either. Look at the stop moulding (the flexible flap nailed to the jambs) and at how far the door overlaps the opening.
Drips just inside after you open the door
Water sitting on the face of the door drips inside as the sections fold over the top. DASMA calls this "a normal operating condition" that "normally results in minimal water infiltration." A seal cannot fix it.
Identify the retainer before you buy a seal
The seal itself is a commodity. The retainer, the channel on the bottom edge of the door that holds it, is not. Clopay's own replacement instructions warn that "garage doors are manufactured with varying types of weather seal retainer designs" and tell owners to contact the maker for the right part. Look closely at the underside of your door with it partly open.
- Double-channel aluminum retainer. Two parallel slots. The seal has a T-shaped edge on each side that slides into them, and the rubber hangs in a loop between. Clopay's "U" shaped astragal fits this style, and its instructions show it on both single-skin steel pan doors and insulated steel sandwich doors.
- Single round ("O") retainer. One slot. Clopay's bulb astragal is a flat strip whose ends you curl together into a bulb so the top forms a single "T" that slides into the slot.
- No retainer at all. Older wood doors often have a strip nailed or stapled straight to the bottom rail. These are replaced by prying off the old strip and fastening a new one, or by adding a retainer.
Before you shop, cut a short piece off one end of the old seal and take it with you, or measure the gap between the two slots and the width of the T edges. A seal whose T edges are slightly too thick will not slide; too thin and it pulls out the first time the door catches on gravel.
| What you see on the door bottom | Seal that fits | How it goes in |
|---|---|---|
| Two parallel slots in an aluminum channel | Double-T loop seal (U-style astragal) | Both T edges slide in from one end |
| One slot | Bulb seal with a single T top | One T edge slides in from one end |
| Strip nailed or stapled to wood | Flat or flanged nail-on seal | Fastened along the bottom rail |
| Channel bent, cracked or corroded | New retainer first | Screwed to the bottom section |
Garage door bottom seal replacement, step by step
Clopay publishes the same basic method for both of its retainer seals, and it works for most slide-in retainers.
- Disconnect the opener. If the door has an automatic opener, disengage it before you start, so nobody can run the door while your hands are under it.
- Open the door and lock it in place. Raise it to the open position and put a C-clamp or locking pliers on both tracks directly below the bottom of the door, so it cannot roll down.
- Pull the old seal out. Slide it out of the retainer from one end. Some doors have screws through the retainer ends holding the seal; take those out first.
- Clean the channel. Scrape out grit and dried mud, and gently straighten any pinched spots with pliers so the new seal can pass.
- Slide the new seal in. Feed the T edges into their slots and pull the seal across the full width. Clopay notes that soapy water helps it slide. Two people make this much easier on a double door, one feeding and one pulling.
- Leave extra at each end. Clopay's instructions say to cut the excess leaving two extra inches past the edge of the door and tuck it into itself to allow for future shrinkage. Refit any screws you removed.
Re-test the opener before you trust it
A new seal is usually taller and firmer than the flattened one it replaces, so the door meets the floor a little earlier. That can change how the opener reads the close position. LiftMaster's manuals say the safety reversal system must be tested after any adjustment: with the door fully open, lay a 1-1/2 inch (3.8 cm) board, or a 2x4 laid flat, on the floor centred under the door and close it. The door must reverse when it hits the board. If it does not, the travel or force settings need attention before the door goes back into daily use. Our garage door won't close troubleshooting guide covers what to check if the door starts reversing on its own afterwards.
When a new seal will not stop the water
If the seal is fresh and fully touching the floor and water still crosses the threshold, the problem is usually the concrete. DASMA's Technical Data Sheet No. 197 recommends a slightly inclined lip where the door rests, shown with a 3° to 5° slope, or a rectangular notch in the slab, below grade, for the door to sit in. The notch should be wide enough for up to a 2 inch track and a 2 inch thick section so the door can still close fully. That is concrete work, best planned when a slab or driveway is being poured.
For an existing slab, DASMA No. 1503 lists the practical upgrades:
- A threshold seal. An aluminum or rubber garage door threshold fixed to the floor, combined with an enhanced bottom seal, "can be a great help."
- Better perimeter seals. Top and side seals help to a degree, and some manufacturers make heavier-duty versions.
- Overlap at the jambs. DASMA suggests sections that overlap the jambs by one inch per side where the building allows.
- Adjustment. Trolley arm and top bracket adjustments, and adjustable jamb brackets, keep the door pressed evenly against its seals.
- Roof water. Gutters, overhangs or a rain ledge over the opening, particularly on west-facing doors that take the brunt of our winter storms.
Side seals: snug, not tight
Amarr's installation instructions have the perimeter seal nailed on with the door closed "for a snug fit so that the seal does not bind the door," and suggest waxing the hard edge of the seal if it drags. If you push the stop moulding in hard against the door to stop a leak, you can end up with a door that sticks or makes the opener strain. Snug contact along the full height is the goal.
Damaged retainers and bottom sections
If the aluminum retainer is bent where a car bumper caught it, split along its length, or so corroded at the ends that a seal will not stay in, replace the retainer rather than forcing a seal into it. On some doors the retainer is part of the bottom section, and a badly dented bottom panel will never seal against the floor however good the rubber is. In that case a section swap may be the better repair; see our page on garage door panel replacement.
Seals, insulation and condensation in a BC garage
A good bottom seal keeps out drafts as well as water, which matters if you have invested in an insulated door or use the garage as a workshop. Our article on whether garage door insulation is worth it in BC covers the door side of that. Be aware that a tightly sealed, heated garage traps moisture from wet cars. DASMA's Technical Data Sheet No. 195 says condensation on a garage door is "not normally a product defect" and recommends ventilating the garage to control humidity. If you see water beading on the inside of the panels after sealing everything up, it may be condensation, not a leak.
The bottom seal is one of the items on our homeowner garage door maintenance checklist. Check it each fall before the heavy rain starts: look for flattening, cracks, and daylight under the door with the lights off.
